Three-In-One Ultra Fine Laboratory Mill and Classifier

The three-in-one combined structure can flexibly realize the integration of jet pulverization, jet grading and mechanical pulverization. It is suitable for 325-10000 mesh (45μm-1μm).

marketing@alpapowder.com Inquire now

Product description

The three-in-one combined structure can flexibly realize the integration of jet pulverization, jet grading and mechanical pulverization. It is suitable for 325-10000 mesh (45μm-1μm).

Performance characteristics

Available D50:1.5～45μm.
Jet mill, air classifier and impact mill are integrated into a whole machine body .
Compact structure, easy operation for transferring one function into another function.
Inert gas is available for protection, high safety guarantee..
High efficiency hermetic structure
Horizontal high-speed classifying wheel up to 18,000 rpm
Mobile mechanical grinding unit are convenient for disassembly and assembly.
Dimensions (length, width, height) 1580x920x1470mm, small grinding area, easy to operate
Can be applied to a variety of grinding processes.
Especially suitable for R&D and testing of new products in research institutes, universities laboratory, research institutes and factory laboratories.
Grinding is completed in closed system, little dust, low noise in a clean and environmentally friendly process.
PLC control system, easy operation.
Inert gas circulation atmosphere, powder classification of flammable and explosive materials
High-precision filter material can be selected with a filtration accuracy of 0.1μm and 99.99 capture
The inner liner can be made of alumina, which is resistant to abrasion and less pollution.
Key parts are fully ceramic to keep the product free from metal contamination.

Working principle

Material enter jet mill (mechanical mill) by automatic feeding system, the particle is separated by high-speed rotating classifier impeller, the qualified powders are collected into cyclone collector, coarse particles are returned to grinding zone. If need to classify the materials separately, adjust impeller speed through frequency converter to achieve classifying different particle sizes.
